    Vertical Free Fall Throat Metal Detect Separator / Food Safety Inspection

    Ask Lasest Price
    Brand Name : SHANAN
    Model Number : VMD series
    Certification : CE, ISO
    Price : negotiation
    Payment Terms : T/T
    Delivery Time : 15work days
    Supply Ability : 100 set/month
    • Product Details
    • Company Profile

    Vertical Free Fall Throat Metal Detect Separator / Food Safety Inspection

    Vertical Free Fall Throat Metal Detect Separator / Food Safety Inspection


    Features of properties:

    1. Collection of detection coil, controller, separation device. Easy to operate and install.

    2. It can save losses of material, because rejection board rapidly rejects unqualified material.

    3. Low height of installation, easy for integrity;

    4. Properties of detection material: dry, good liquidity, no long fiber, no conductivity;

    5. Temperature of detection material: less than 80℃;If exceeds 80℃, can choose special components.

    6. Controller can be installed around detection place about 10m.

    7. Protection level: IP65

    8. It is mainly used for detection of loose granule materials(8mm). Those materials fall into detection coil with gravity. The machine can be applied in plastic, food, chemical industry and so on.


    Application:

    • Food industry, chemical industry, pharmaceutical industry, plastic industry, packaging industry, etc .


    Advantages:



    1. Protect production device;

    2. Enhance production efficiency;

    3. Improve the availability of raw material;

    4. Enhance product’s quality;

    5. Reduce the expense of maintenance and shuts-down;



    Technical Parameters:

    Model

    Dimension

    (mm)

    Sensitivity (Fe)Sensitivity (SUS)

    Air

    compression

    Max.

    throughput

    (L/H)

    Defectives eliminated

    time

    Installation

    height

    (mm)

    VDM-25250.2mm0.3mm3~5Bar3000.3~5s330
    VDM-35350.3mm0.5mm3~5Bar4000.3~5s330
    VDM-50500.3mm0.6mm3~5Bar20000.3~5s330
    VDM-70700.8mm1.2mm3~5Bar50000.3~5s330

    VDM-

    100

    1000.8mm1.5mm3~5Bar120000.3~5s473

    VDM-

    120

    1201.0mm1.8mm3~5Bar160000.3~5s473

    VDM-

    150

    1501.2mm2.0mm3~5Bar250000.3~5s600

    Packing details:


    Gravity Metal Separator Free Fall Metal Separator for Plastic Industry Package:
    1. Plastic wrap moisture
    2. Fixed on the bottom of the wooden box
    3. Standard export wooden box packaging, reinforcement




    Warranty Period



    (a) Standard 12 (Twelve) months dated from delivery (Consumable parts and man-made broken are not included); ; If need much longer warranty period, please contact with our salesman. During warranty period, we offer replaced new parts for free.


    (b) Out of warranty period, we will offer spare parts and technical support too and help customer to solve problems; If need replace parts, we will charge parts costs
