Stainless Steel Conveyor Belt Metal Detector Manufacturer For Food Production Line With Automatic Alarm And Rejector System

GUANGDONG SHANAN TECHNOLOGY CO.,LTD
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Stainless Steel Conveyor Belt Metal Detector Manufacturer For Food Production Line With Automatic Alarm And Rejector System from wholesalers

    Buy cheap Stainless Steel Conveyor Belt Metal Detector Manufacturer For Food Production Line With Automatic Alarm And Rejector System from wholesalers
    • Buy cheap Stainless Steel Conveyor Belt Metal Detector Manufacturer For Food Production Line With Automatic Alarm And Rejector System from wholesalers
    • Buy cheap Stainless Steel Conveyor Belt Metal Detector Manufacturer For Food Production Line With Automatic Alarm And Rejector System from wholesalers
    • Buy cheap Stainless Steel Conveyor Belt Metal Detector Manufacturer For Food Production Line With Automatic Alarm And Rejector System from wholesalers
    • Buy cheap Stainless Steel Conveyor Belt Metal Detector Manufacturer For Food Production Line With Automatic Alarm And Rejector System from wholesalers
    • Buy cheap Stainless Steel Conveyor Belt Metal Detector Manufacturer For Food Production Line With Automatic Alarm And Rejector System from wholesalers

    Stainless Steel Conveyor Belt Metal Detector Manufacturer For Food Production Line With Automatic Alarm And Rejector System

    Ask Lasest Price
    Brand Name : SHANAN
    Model Number : SA-990
    Certification : CE, ISO
    Price : negotiation
    Payment Terms : T/T
    Supply Ability : 100 set/month
    Delivery Time : 15work days
    • Product Details
    • Company Profile

    Stainless Steel Conveyor Belt Metal Detector Manufacturer For Food Production Line With Automatic Alarm And Rejector System

    About Shanan.pdf

    Stainless Steel Conveyor Belt Metal Detector Manufacturer For Food Production Line With Automatic Alarm And Rejector SystemStainless Steel Conveyor Belt Metal Detector Manufacturer For Food Production Line With Automatic Alarm And Rejector SystemStainless Steel Conveyor Belt Metal Detector Manufacturer For Food Production Line With Automatic Alarm And Rejector SystemStainless Steel Conveyor Belt Metal Detector Manufacturer For Food Production Line With Automatic Alarm And Rejector System

    Food Production Line Metal Detector Price


    Quick details:
    Machine specification


    Detection Width

    (mm)
    400
    300 customized
    Detection Height
    (mm)
    100
    120
    150
    200
    250
    300
    350
    400
    Detection
    Sensitivity
    Fe(Φmm)
    ≥0.6
    ≥0.8
    ≥1.0
    ≥1.2
    ≥1.5
    ≥2.0
    ≥2.5
    ≥3.0
    Non-Fe(Φmm)
    ≥1.0
    ≥1.2
    ≥1.5
    ≥2.5
    ≥3.0
    ≥3.5
    ≥4.0
    ≥4.5
    304Sus(Φmm)
    ≥1.2
    ≥1.5
    ≥2.0
    ≥2.5
    ≥3.0
    ≥3.5
    ≥4.0
    ≥4.5
    Alarm and rejector system
    Automatic stop by alarm and sound or push rod or falling drop
    Machine structure
    Full structure takes of stainless 304
    Machine size (mm)
    L1520mm×W830mm×H1100mm
    if customized it will according to customized size
    Machine weight
    Around 250KG if customized the weight will different
    Voltage and power
    220V 50Hz 90W
    Load ability of belt
    5-25KG
    conveyor belt running speed:25-30m/min or customized various
    Height of line
    750mm±50mm can customized
    Note :Normal size machine have stocks. Unnormal size machine have to customized

    • Parameters
    1. Identify a variety of magnetic and non-magnetic metals like iron, stainless steel, aluminum, etc. even if the metal contained in the food products.
    2. Adopt the-double-circuit signal detection make it high sensitible and strong anti-disturbance.
    3. With the double circuit signal demonstration function: When the metal good is passing, the signal light will demonstrate different inductions according to the size of the metal objects.
    4. With the adjustment function of products effect such as moist products and products including sugar or salt, they all can make the machine create a signal from metal, which is actually has no metal in it, so it gets wrong information from the products and affects the detection result. So it can reduce the products’ effect to get better detection result via using this machine with this function.

    5. Get rid of missing detection. When there are several metal signals passing, the machine will automatically record the signal amount, therefore it won’t have miss detection results.

    6. Control system: Controled by ADLINE microprocessor.

    7. Conveyors: PU (polyurethane) or PVC food grade conveyor.
    8. Special transport mechanism designed can maximize the sensitivity of metal detectors.
    9. Flexible modular design can be customized according to different requirements .

    10. Easy for workers to clean because of mirror stainless steel with open transport system. .

    11. Conveyer belt meet FDA standards.
    12. Meet the requirements of IFS and HACCP certificates. There are a variety of options to exclude institutions depending on the application

    Stainless Steel Conveyor Belt Metal Detector Manufacturer For Food Production Line With Automatic Alarm And Rejector System




    How to select a metal detector for yourself:

    Determine the types of metal that need to be tested. There are two main types of metals: ferrous and non-ferrous. The ferrous metal comes from iron. Non-ferrous metals are all others. Carefully inventory the types of metals that may eventually appear in your product.

    What size of metal contaminants do you need to filter? For this problem, you need to be pragmatic and realistic, because if you specify too much sensitivity, you will get too many false alarms and vice versa.

    Understand the operating environment and product characteristics - The operating environment includes temperature and whether water, dust or chemicals may come into contact with metal detectors and possible electric fields. In addition, is the product fresh or frozen, and the package is still exposed, scanned separately or in a box? All of these factors will be used to design the metal detector that best meets your needs.

    Reject System Considerations - The most common way is to use a propeller or blower to transport metal detection products. However, you can save space by stopping the conveyor and starting the warning light. Further more, an optional lockable collection container prevents unauthorized employees from accessing rejected products.
