SAMDCW-300 Combination with Metal detector & Checkweigher
American technology Multi-frequency Metal Detector Features:
Newly designed metal detectors can be customized to meet your
unique needs and achieve lower operating costs than upgrading or
repairing existing systems. Metal detectors are available in
conveyor, reverse loading and in-line systems designed to the
required specifications.
Other cost-saving advantages include:
• Durable HD Heads - withstands all cleaning environments.
• Increased system sensitivity and stability—fewer inappropriate
rejections.
• Unique case design and epoxy filling—reliable in thermal shock
environments.
• Probe is constructed from Type 316 stainless steel alloy - good
corrosion resistance.
• Standard APEX electronics and software - fully compatible with
other models.
• Excellent long-term stability—minimum maintenance costs.
1. The core part is carefully developed with leading digital
technology and original imported chips. The inside of the detection
coil is formed by potting and sealing, which has the
characteristics of high detection accuracy, stable performance and
strong anti-interference ability.
2. It can be produced with a variety of frequencies according to
product characteristics, and has the function of product testing
data storage, which can store a variety of product testing data,
and has a wide range of applications.
3. Adopt intelligent identification technology, with self-learning
and memory functions, can automatically recognize and memorize
product characteristics, running speed in the range of 1-1000 m/min
(need to increase the speed), effectively eliminate high oil, high
salt, high temperature, high speed interference caused by various
"product effects" such as high moisture content.
4. Simple and friendly operation interface, using a conversational
D screen, parameters can be set quickly and easily through a simple
key control interface; it can detect a variety of products
including different product signals (characteristics), and a single
setting can ensure a high level of The detection accuracy, no need
to re-adjust, set the program.
5. Modular components are more conducive to cleaning, replacement
and maintenance.
6. Various removal devices (such as air blowers, push rods, flaps,
etc.) can be used according to customer needs. Lightweight, special
for large packaging and heavy-duty body design.
7. Made of stainless steel, the whole machine has excellent
dustproof and waterproof performance.
Checkweigher Application:
This product is suitable for testing whether the weight of a single
product is qualified, and is widely used in electronics,
pharmaceuticals, food, beverages, health care products, daily
chemicals, light industry, agricultural and sideline products and
other industries. Such as cosmetics for daily chemical products
(including beauty cosmetics, cleaning, cosmetics, skin care
products, hair cosmetics, etc.); detergents (including soap,
washing powder, detergent, etc.); oral products (including
toothpaste, mouthwash, etc.); Other chemical products (including
shoe polish, floor wax, deodorant, insect repellent), etc.
Checkweigher Features:
Strong versatility: The standardized structure of the whole
machine and the standardized human-machine interface can complete
the weighing of various materials;
Simple operation: using Weilun color man-machine interface, fully
intelligent and user-friendly design; the conveyor belt is easy to
disassemble, install and maintain, and is easy to clean;
Adjustable speed: the motor is controlled by frequency
conversion, and the speed can be adjusted as required;
High-speed and high-precision: using high-precision digital
sensors, fast sampling speed and high precision;
Zero tracking: can be manually or automatically cleared, and
dynamic zero tracking;
Report function: built-in report statistics, the report can be
generated in EXCEL format, can automatically generate a variety of
real-time data reports,
The U disk can store statistical data for more than one year, and
can hold the production status at any time; provide the factory
parameter setting recovery function, and can
Store a variety of formulas, easy to change product specifications;
Interface function: Reserve a standard interface for easy data
management,
, can communicate with PC and other smart devices;
Self-learning: You don’t need to set parameters after creating
new product formula information. Use the self-learning function to
automatically set the appropriate parameters of the device, and
store them for easy recall when you switch products next time.
(2000 parameter storage entries can be added).
Operating mode: three operating modes
a. Dynamic mode: normal pipeline mode;
b. Static mode: After the material enters the weighing platform,
the weighing platform stops running, and weighs to improve
accuracy, suitable for products with less than 20 passes per
minute;
c. Energy-saving mode: The energy-saving mode can be turned on on
the basis of modes a and b, and set the shutdown time without
material passing. When the equipment is idling, it will
automatically stop after a long period of time, and then
automatically start when there is material passing.
Fault self-detection: self-detection: whether the motor,
inverter, AD, sensor and photoelectricity are normal, the cause of
the fault, and the pilot detection of the cylinder, solid state
relay, and solenoid valve. It is convenient for non-professionals
to check and repair.
Peripheral equipment communication: standard RS-485 and RS-232
dual communication port output.
a. The RS-485 interface is MODBUS, RTU standard protocol, but the
write address (57600bps, 8, N, 1, and the slave station number is
3) can not be modified.
b. The RS-232 interface is a self-defined protocol, and you can set
the content of the command to send by yourself. (57600bps, 8, N, 1)
can be modified.
External communication equipment such as printers or inkjet
printers can also be connected with front and rear packaging
machines and production equipment to feed back the weighing results
so that the formula parameters can be automatically modified.
Chinese input method
a. The name of the formula can be input in Chinese, which is more
intuitive when searching and switching formulas.
b. With RS-232 communication port, it can send Chinese characters
of Unicode string to peripheral equipment. (Suitable for printing
Chinese characters with external printer or marking machine).
Parameter:
| Item | SAMDCW-300 Combination with Metal detector & Checkweigher |
| Power | Single phase AC220V, 50Hz |
| Rated power | 0.4KW |
| Single weighing range | ≤3000g |
| Weighing accuracy range | ±0.5~±2g |
| Minimum scale | 0.1g |
| Metal detection channel width (mm) | 300 |
| Metal detection channel height (mm) | 120 |
| Product storage parameters | 200 kinds |
| Metal detection sensitivity Ferrous | ≥1.0mm |
| Metal detection sensitivity non-ferrous | ≥1.2mm |
| Metal detection sensitivity stainless steel | ≥2.5mm |
| Transfer speed | 30~80m/min |
| Maximum speed | 80 pcs/min |
| Inspection item size | ≤300mm(L)*290mm(W) |
| Scale conveyor belt size | 450mm(L)*300mm(W) |
| Length of the whole machine | 2100mm(L)*560mm(W)*1222mm(H) |
| Elimination method | Double Pusher type |
| Conveyor belt material | Food grade white PU material (with third-party inspection report) |
| Alarm method | Automatically stop operation when metal foreign body is detected,
buzzer alarm, and pusher rejector |
| Control System | High-speed A/D sampling controller |
| Preset product number | 2000pc |
| Conveying direction | Facing the machine, left to right |
| External air source | 0.6-1Mpa |
| Air pressure interface | Φ8mm |
| Working environment | Temperature: 0℃～40℃,Humidity:30%～95% |
| Machine material | The whole frame is made of 304 stainless steel, in line with HACCP,
GMP, FDA, CAS and other standards |
| Operation screen display | Chinese, English |
| Other standard equipment | Windshield (colorless and transparent), calibration weight |
| Height of belt surface from ground | 700+100mm(can customize) |
| Remark | 1. The above sensitivity parameters are the test results when the
machine is empty and there is no environmental interference. The
actual application will be slightly different due to the use
environment and the component interference of the detected object! 2. Depending on the size of the product being tested and the
working environment in which the equipment is running, the accuracy
of the testing speedometer is also slightly different. |
