Application:
Metal detectors are mainly used for the detection and inspection of
metal impurities in food. Widely used in meat, frozen meat, fungi,
candy, mushrooms, seafood, salt, beverages, food, fruits and
vegetables, dairy products, aquatic products, health products,
additives and condiments. Can also detect rubber, plastic,
textiles, leather, chemical fiber, toys, medicine, health products,
biological products, cosmetics, gifts, packaging, paper products,
etc.
| Technical Data |
| Theory | Balanced Coil |
| Aperture Size | 400 mm *120mm |
| Belt Speed | 30m/min(Adjustment) |
| Reject system | Arm Pusher /swing arm (Optional) |
| Alarm | Buzzer |
| Power | Single phase AC220V 50-60HZ |
| Rated Output | Appr.90W |
| Dimension | 1000mm(L)*900mm(W)*900±50mm(H) |
| Weight | Appr.190Kg |
| Tunnel Size | Sensitivity | | 400mm*100mm | Fe Φ 0.8mm; Sus Φ1.2mm | | 400mm*120mm | Fe Φ 1.0mm; Sus Φ1.8mm | | 400mm*150mm | Fe Φ 1.2mm; Sus Φ2.0mm | | 400mm*200mm | Fe Φ 1.5mm; Sus Φ2.5mm |
|
[FEATURES]
1. Based on high speed 32bit CPU control circuit
2. Large color D display, easy to operate
3. Multi-functional OS and dual language
4. Full digital signal processing and transferring
5. High-precision auto adjustment for phase angle
6. Newly designed SUS machine frame with high protection grade
7. Intelligent product study mode can fit for more types of product
8. Automatic rejection module
9. Multi-functional stainless steel frame and adjustable height
10. Match different production lines
11. Automatic product learning/studying function
12. Have moving wheels, height are adjustable
[PURPOSE]
Very best performance for large effect products such as milk,
sausage, fresh meat, fresh, sauce, filling, salt& smoking products.
Widely use for detecting metals in food, pharmaceutical products,
rubber, garment, plastic, beverage, chemical and any other
industries to ensure product safety and protect your brand.
Description:
High Sensitivity Metal Detector is new arrival food metal detector
. It has touch screen , 10 level adjustable sensitivity and
memory 10 kinds of products etc .But also it has more higher
reliability and stability on check products with water and salt.
1. Adopt the theory of balance, more reliable;
2. Phase-adapted technology can adapt products in order to
effectively eliminate product effect.
3. Combination of DSP and Microprocessor is applied to process
testing data of detection signal, which can enhance detection
efficiency.
4. To stop mistaking in transmission & reception in advance, the
detector handles many operations. Easy to adjust the detecting
parameters.
5. Large D display with Chinese & English language and so on;
Consumer can choose according to their needs.
6. Have self- learning study function, can automatically digitally
learn and store product’s features.Easy to operate without manual
participation to adjust technical parameters.
7. It can store more than 100 kinds of testing data of products.
8. Automatic rejection system can be customized according to
consumer’s requirements, which can improve production efficiency
and save labor costs.
9. Suitable for wet, dry ,dust ,dew environment , made of stainless
steal ,has HACCP attestation , waterproof IP65
