    10 - 80 Meter Adjustable Conveyor Weight Checker Combined With Metal Detector IP67 Waterprood Rating

    Ask Lasest Price
    Brand Name : SHANAN
    Model Number : VCM-3025
    Certification : CE, ISO
    Price : negotiation
    Payment Terms : T/T
    Supply Ability : 100 set/month
    Delivery Time : 15work days
    • Product Details
    • Company Profile

    10 - 80 Meter Adjustable Conveyor Weight Checker Combined With Metal Detector IP67 Waterprood Rating


    About Shanan.pdf


    Dynamic Checkweighing is a method of safe guarding within the food and packaging industries for product weights. A Checkweigher system will check weights of products whilst in motion, rejecting any products that are over or under the set weight. All our Checkweigher systems are approved to both OIML and MID (EC TAC) specifications and include Automatic Mean Weight correct, which helps to ensure weight legislation.

    Widely used in package workshop with compact space.


    Dynamic Checkweighers are easy to use with intuitive full colour touchscreens and icon-driven menus as well as offering fast inspection and product set up, automatically optimising the systems for each product type allowing you to learn and switch within minutes. Our machines are made for products ranging from small and light sachets right through to Heavy weight boxes.


    Checkweigher VCM Series

    • 1. Compact design, saving space and installation cost
    • 2. Metal detector and checkweigher is perfectly connected in one frame, to achieve lowest requirements of the production line and install the machine in workshop conveniently and effectively


    Specifications

    ModelVCM-2
    Detecting Range1kg- 25kg
    Scale Interval0.1g
    Accuracy(??)±1g
    Detecting Speed(Max speed)155pcs/min
    Maximum Belt Speed80m/min
    The Weighed Product SizeWidth220mm
    Length350mm
    Height70mm110mm140mm170mm
    Weigher Platform SizeWidth230mm
    Length450mm
    Height80mm120mm150mm180mm
    SensitivityFe?0.5mm?0.7mm?0.7mm?0.7mm
    SUS?1.2mm?1.5mm?1.5mm?2.0mm
    Product Storage Quantity100 kinds
    Segments Number of Sorting2 or 3
    RejecterRejecter Optional
    Power SupplyAC220V (Optional)
    Degree of ProtectionIP30/IP54/IP66
    Body MaterialStainless Steel (SUS304)

    10 - 80 Meter Adjustable Conveyor Weight Checker Combined With Metal Detector IP67 Waterprood Rating10 - 80 Meter Adjustable Conveyor Weight Checker Combined With Metal Detector IP67 Waterprood Rating 10 - 80 Meter Adjustable Conveyor Weight Checker Combined With Metal Detector IP67 Waterprood Rating
