Brand Name : | SHANAN |
Model Number : | VDF-5005 |
Certification : | CE, ISO |
Price : | negotiation |
Payment Terms : | T/T |
Supply Ability : | 100 set/month |
Delivery Time : | 15work days |
Tunnel Metal Detector , Food Inductrial Metal Detector , HACCP ,
ISO 9001 , CE Certified
Using a tunnel-type metal detector, it is possible to detect all
kinds of metal contaminants, including ferrous, non-ferrous and
even difficult to detect grades of stainless steel. When integrated
with conveyor equipment, tunnel metal detector systems can provide
advanced metal detection and rejection solutions for food and
non-food processing applications.
With a wide range of aperture size ranges and feature sets,
Safeline tunnel metal detectors for conveyor systems offer an ideal
solution to detect all types of metal for inline food and non-food
processing applications.
All METTLER TOLEDO Safeline tunnel metal detectors incorporate robust construction standards to provide stable, reliable, and consistent metal detection performance to detect all types of metal in a wide range of food and non-food processing applications, regardless of the working environment.
Built-in performance verification routines to comply with retailer
codes of practice and food safety regulations are standard in
Safeline tunnel metal detectors for conveyor applications. A range
of connectivity options and protocols are available to support your
data collection and compliance needs.
Technical parameters:
(mm)Detection Height | 100 | 120 | 150 | 200 | 250 | 300 | 350 | 400 | |
Detection Sensitivity | Fe(Φmm) | ≥0.6 | ≥0.8 | ≥1.0 | ≥1.2 | ≥1.5 | ≥2.0 | ≥2.5 | ≥3.0 |
Non-Fe(Φmm) | ≥1.0 | ≥1.2 | ≥1.5 | ≥2.5 | ≥3.0 | ≥3.5 | ≥4.0 | ≥4.5 | |
304Sus(Φmm) | ≥1.2 | ≥1.5 | ≥2.0 | ≥2.5 | ≥3.0 | ≥3.5 | ≥4.0 | ≥4.5 | |
Alarm and rejector system | Automatic stop by alarm and sound or push rod or falling drop | ||||||||
Machine structure | Full structure takes of stainless 304 |
Product advantages:
◆Even product with embedded in metal also can identify a variety of
magnetic and non-magnetic metals (such as iron, stainless steel,
aluminum, etc.).
◆ Adopts the double circuit signal detection circuit, high
sensitivity and strong anti-disturbance ability.
◆ Has the double circuit signal demonstration function. When a
metal object passes, the signal light will show different
inductance depending on the size of the metal.
◆ Adjustment function by products effect, such as moist products,
products including sugar or salt, they all can make the machine has
the signal of metal, which is actually has no metal, so it gets
wrong information from the products and affect the detection
result. So use this machine with this function can reduce the
products’ effect to get better detection result.
◆ Can avoid missing detection. When several metal signals are
passing, the machine will automatically record the signal amount,
so it won’t have missing detection.
◆ Control system: ADLINE microprocessor controller.
◆ Conveyors: Joint-body PU (polyurethane) Conveyor.
◆ Special transport mechanism designed the maximize sensitivity of
metal detectors.
◆ Flexible modular design can be customized according to different
requirements.
◆ Mirror stainless steel with open transport system. Easy to clean.
◆ Conveyer belt adopts imported white ones safe to food.
◆ Meet the requirements of IFS and HACCP certification. There are a
variety of options excluded
institutions depending on the application.
![]() |
