High Accuracy Industrial Metal Detectors With Large Throughput
Products Sorting Quality Detecting
Food Industry Information:
Within the food production industry, there is perhaps no bigger
contaminant material than metal. Due to its abundant use in all
stages of food processing, the material is often found in the raw
foodstuffs. It is essential that this is located and move before
the packaging stage to guarantee the safety of consumers and the
legitimacy of your company.
Metal detectors catering specifically to the food industry should
be a compulsory piece of equipment for any area of food production,
including baked goods, fruit and vegetables, dairy, fish, meat,
cereals, beverages and more.
With the vegetable processing industry for example, the sheer range
of products catering to a variety of vegetables means that here is
always a risk of contamination from metal, through broken equipment
or delivery.
There is also the risk of sabotage within food production,
especially as a large percentage of product is imported overseas
where rules and regulations are not necessarily as strict as within
the United Kingdom. By having a metal detector, the risk of
sabotaged food product reaching the consumer is greatly reduced.
Detect object:
Almost all metal detectors in the food industry are able to detect
three core groups of metal contaminants:
Ferrous metals are easily detected as they are both magnetic and
conductive
Non-Ferrous metals are non-magnetic but are strong conductors and
are therefore easily detected.
Stainless steel contaminants are perhaps the toughest to pick up
because of their poor conductivity and non-magnetic. However, most
reliable metal detectors designed for food production will be able
to detect these contaminants.
Generally, there are four types of metal detectors that are popular
within the food industry:
Search Heads are used frequently for inspection of fruits,
vegetables, cereals, meats and bread.
Conveyor based Systems are used frequently for inspection of
fruits, vegetables, cereals, meats, yogurt and bread.
Pipeline for Pumped Products are used frequently for beverages,
sauces, soups and dairy.
Vertical Fall Systems are used frequently for powders, grains and
granules.
Standard replace use Layout parts :
One set of hex wrench
Full sets of the range calibration test cards(Ferrous,non-ferrous
,Stainless steel)
Warranty
12month labor and parts
Full life technical support
Packing and shipment
Full machine takes of two layer package
Prepackage takes of plastic bags conveyor the full machine and the
key parts have foam plastic protection
Eng package takes of Strong ploy wooden case that meet different
country import standard
Installation and use
When you takes of the package .up the rubber base ,use wheel move
it to your work place.
Then down the rubber base and fasten it..keep all the base in a
horizontal
Then running the machine few hours before use ,No need complex
installation .
The user guide will make in book and Videos for customer reference
.
Sensitivity reference
Details Tunnel size | 40*12cm | 40*15cm | 40*20cm | 50*15cm | 50*20cm | 50*25cm | 50*30cm |
| Sensitivity Fe(mm) | 0.8 | 1.0 | 1.2 | 1.0 | 1.2 | 1.5 | 2.0 |
| Sensitivity SUS(mm) | 1.5 | 2.0 | 2.5 | 2.0 | 2.5 | 3.0 | 3.5 |
| Detection height | 120 | 150 | 200 | 150 | 200 | 250 | 300 |
| Detection width | 400 | 500 |
| Belt speed |
10-35 meters per minute adjustable |
| Alarm method | Light and sound and optional reject |
Optional reject 1 :Push rod
Optional 2 flap drop
Optional 3 Air blast
