LED Display Multi Zone Metal Detector Walk Through With Four Key Panels Operation

General specification:

• Portable metal can be excluded
• Dual high-brightness red LED display
• Integrated four key panels operation
• Multiple network ports
• External control alarm device port
• Secondary development port/ upgrade port
• Count the number of people passing through
• The funtion of counting Alarm times
• Multi zones detect and alarm at the same time
• Smart partition function to detect large objects
• Password protection Function
• The super brightness SMD
• Super brightness SMD double zones indicator
• 50 alternative operating frequencies
• Multiple alarm sound selection modes
• Choose the overall safety level of 1-20
• 4 independent probes, 4 detecting zones

Advantages:

• Simple and elegant front panel design, remote control, easy to use and convenient.
• With upgrade ports, we provide lifelong upgrade services, it can be achieved the secondary development
• according to user's need
• Slant main chassis designed all-metal structure , patented large countersunk head bolts for doors, easy to
• assemble , the structure is more stable, more stability .
• The 3D multi-angle infrared design, can better prevent the interference of strong light, sunlight and other
• external light ( patented technology )
• The super brightness SMD double district alarm indicators , multi-angle display the hiding place of prohibited
• items.
• Full wraparound high booties , double pivot design , and not affected by uneven ground , it can be better to ensure the stability of the door , which has beyond the traditional design.
• On each side of the door designed the power interface, which can be better meet the users' needs

Technical parameters:

• Vertical dimension:2230x580x830mm
• Vertical channel size:2000*700mm
• Detection door packing size:2290x600x200mm
• Main box packing size:755x210x340mm
• Net weight of main box/detection door:56.6KG
• Gross weight of main box/detection door:62.8KG
• Working voltage:90V~240V 50/60Hz
• Power consumption:20W
• Working frequency range:1-50 bands
• Working environment temperature:-20℃ ~ 65℃
• Installation environment :(W) 100cm* (L) 200cm(minimum range without metal)
• Be detected in a zone:Maximum sensitivity ≥ 10g metal

Tips:

• 12month labor and parts full life technical support
• Full machine takes of two layer package
• Prepackage takes of plastic bags conveyor the full machine and the key parts have foam plastic protection
• All package takes of Strong ploy wooden case that meet different country import standard Installation and use
• When you takes of the package .up the rubber base ,use wheel move it to your work place.
• Then running the machine few hours before use ,No need complex installation .
• The user guide will make in book and Videos for customer reference .

Company information:

we are a professional metal detector manufacturer.
we accept kinds of metal detector customized.

Guangdong Shanan Technology Co.,ltd is a leading manufacturer of metal detectors, X-ray inspection machines, and checkweighers in China. With over 15 years of experience in the industry, our company has established a reputation for quality, innovation, and customer service.

We are proud to be an Audited Supplier by Walmart of Mexico, a distinction that reflects our commitment to excellence in every aspect of our operations. In addition, we are the only factory in this industry certified as a Super Factory by in China, a testament to our ongoing efforts to push the boundaries of what is possible in terms of manufacturing efficiency, product quality, and customer satisfaction.

Our team includes more than 20 professionals in R&D, all of whom have contributed to the nearly 20 patents that we have obtained over the years. Our factory is certified for ISO9001 and ISO14001, and all of our machines are built to meet CE, FDA, HACCP, GMP, and IFS standards.

At our company, we take pride in our ability to provide customers with the latest technologies and exceptional service. We offer a wide range of products to meet the needs of different industries and applications, including food and beverage, pharmaceuticals, cosmetics, and more. Whatever your needs may be, our team is here to help you find the right solution for your business.

We are passionate about food safety and take our role in ensuring the safety and quality of the food supply chain very seriously. By partnering with us, you can be confident that you are working with a company that is committed to excellence in everything we do.

Thank you for considering our company as your partner in metal detection, X-ray inspection, and checkweighing technology. We look forward to working with you to achieve your goals and exceed your expectations.
