SACW-210 S
Weighing and sorting machine is a kind of application to various automation lines.And automatic weight detection on the logistics conveyor system, upper and lower limits or according to the weight check High-tech automated sorting equipment for testing products. Universal weighing More suitable for online automatic weighing of boxed, parcel box, single product sample packaging products Detection, underweight detection, missing installation detection, attachment missing detection, etc.
| Product features and advantages: |
Designed to increase productivity and increase productivity; high-speed sampling control enables equipment speed Faster and higher precision; 10-inch large operation screen, easy to use human-machine interface 3 Independent operation in minutes; reinforced stainless steel structure, IP65-68 waterproof type (optional) can store a variety of recipes, easy to replace product specifications; modular structure makes the machine Simple, easy to maintain, easy to clean; manual or automatic zero and dynamic zero tracking;Generate EXCEL format and a variety of real-time data reports, U disk storage for more than 1 year of data support the production situation at any time; communicate with PC and other smart devices;Centralized control of multiple checkweighers by one computer and man-machine interface; using frequency controlMotor, speed can be adjusted as needed.
Weighing and sorting is suitable for testing whether the weight of a single product is acceptable or the product is packaged.Whether there are any omissions in the process, widely used in pharmaceutical, food, beverage, electronics, health care Products, daily chemicals, light industry, agricultural and sideline products and many other industries. Such as boxed medicines, food industry
Description:
The High Speed Conveyor Weight Checker / Dynamic Checkweigher Machine is a highly efficient and accurate weighing system used to ensure compliance with label weight regulations and to minimize product giveaway. It is designed to detect the weight of single products and compare them with the target value, eliminating unstandard products with a sorting device.
Quick Details:
Place of Origin: China
Brand Name: SHANAN
Model Number: VC-15
Material: Stainless Steel
Type: Check Weigher
Color: Optional
Function: Weighing
Scale Use: Kitchens, Offences, Warehouses
Display Type: D Display
Power Supply: 110v or 220v
Accuracy: 1g
Rated Load: 20KG
Warranty: 12 Months
Certification: CE, ISO
Product Name: Weighing Scale
Max Speed: 60-120 Pieces/Minute
Parameters:
- Weight range: Max 1000g
- Max accuracy: ±0.5g
- Screen resolution: 0.01g
- Rejection: deflector rod
- Belt height from earth: 750±50MM (can be customized)
- Products recipe storage: can store 100 kinds
- Power supply: customized 110---220V±20% 50HZ
- Machine structure: Full stainless steel 304
- Full machine weight: approx 100kg
Features:
- Solid SUS304 stainless steel structure for good performance
- Belt disassembling without tools, making it easier to clean
- Rejecter system options: automatic stop by sound and light, air blast, or pneumatic push rod
- Emergency stop button for safety working condition
- Advanced digital signal processing for high speed and stable weighing
- Liquid crystal and tangible screen for easy operation
- Self-diagnosis function for detecting Rom/Ram, A/D light electric tube
Application:
The High Speed Conveyor Weight Checker / Dynamic Checkweigher Machine is suitable for use in a variety of industries, including food, pharmaceutical, and other manufacturing industries. It is ideal for detecting and eliminating unstandard products, reducing customer complaints, speeding up production, and minimizing product giveaway.
