Food grade metal detector / metal detector for refrigerated and
frozen food
Why are metal detectors used in the food industry?
food Metal detectors for food primarily are used for the purpose of
consumer protection. Despite maximum care metallic contaminations
of food products during the production process cannot be fully
excluded. Metal particles that enter the product during the
production process or already are contained in the raw material may
cause serious injuries of consumers. The consequences for the
producing company are numerous and serious and include compensation
claims and expensive recalls.
Even bigger and longer-lasting damage is caused by the negative
brand image and the loss of consumer trust caused by impure food
products.
Metal detectors for food provide effective protection against
ferrous and non-ferrous metals (aluminium, stainless steel, etc.).
They can be installed in every step of the production process and
can be used for many different applications, e.g. for the
inspection of bread and bakery products, meat and sausage product,
fruit, vegetables, dairy products, spices, sugar, etc.
In addition to consumer protection, metal detectors also are used
to protect machinery. Even smallest metal particles can lead to
machinery failure. Expensive repairs and production downtimes are
the consequences, often followed by revenue decreases.
Product advantages:
Full Stainless steell 304 food grade structure
Digital singla process can records 100 kinds of products
Adjustment speed from 10-35 meter /minute
High sensitivity with 6012 inspection tunnel
Food grade PU conveyor belt conform to American FDA food grade
Application :
Food industry
Medical industry
Food additives
Baby products
Health products
Other industry that need reject and detect metals
Warranty
12month labor and parts
Full life technical support
Detail Specification:
| Model | VCF series |
| Machine specification | Normal machine | Customized width |
| (mm)Detection Width | 400 | 500 customized |
| (mm)Detection Height | 100 | 120 | 150 | 200 | 250 | 300 | 350 | 400 |
| Detection Sensitivity | Fe(Φmm) | ≥0.8 | ≥1.0 | ≥1.2 | ≥1.5 | ≥2.0 | ≥2.5 | ≥3.0 | ≥3.5 |
| Non-Fe(Φmm) | ≥1.0 | ≥1.2 | ≥1.5 | ≥2.0 | ≥2.5 | ≥3.0 | ≥3.5 | ≥4.0 |
| 304Sus(Φmm) | ≥1.2 | ≥1.5 | ≥2.0 | ≥2.5 | ≥3.0 | ≥3.5 | ≥4.0 | ≥4.5 |
| Alarm and rejector system | Automatic stop by alarm and sound or push rod or falling drop |
| Machine structure | Full structure takes of stainless 304 |
| Machine size (mm) | L1520mm×W830mm×H1000mm if customized it will according to
customized size |
| Machine weight | Around 250KG if customized the weight will different |
| Voltage and power | 220V 50Hz 90W |
| Load ability | 5-25KG conveyor belt running speed :25-30m/min or customized
various |
| Height from the earth | 750mm±50mm can customized |
| Note :Normal size machine have stocks. Unnormal size machine have
to customized |
Reject system(optional)
Optional reject 1 :Push rod
Optional 2 flap drop
Optional 3 Air blast
